Kern Analytical Balance | ABJ 220-4NM
The bestseller in analytical balances, with high-quality single-cell weighing system
- Automatic internal adjustment in the case of a change in temperature ≥ 2 °C or timecontrolled every 4 h, guarantees high degree of accuracy and makes the balance independent of its location of use.
- Dosage aid: High stability mode and other filter settings can be selected.
- Simple recipe weighing and documenting with a combined tare/print function. In addition, the ingredients for the recipe are numbered automatically and printed out with their corresponding number and nominal weight.
- Automatic data output to the PC/printer each time the balance is steady.
- Identification number: 4 digits, printed on calibration protocol freely programmable.
- Protective working cover included with delivery.
Kern Analytical Balance | ABJ 220-4NM Technical Data
| Weighing capacity [Max] | 220 g |
| Readability [d] | 0,0001 g |
| Units | g, mg, ct |
| Linearity | ± 0,0003 g |
| Reproducibility | 0,0002 g |
| Stabilization time | 3 s |
| USP Minimum weight of sample (k = 2, U = 0.1%) | 400 mg |
| Interfaces | RS-232 (optional) |
| Adjustment options | Internal calibration (automatic), Adjusting with internal weight (manual) |
| Ambient temperature | 10 °C – 30 °C |
| Dimensions weighing surface (Ø) | 91 mm |
| Material draught shield | glass |
| Material housing | cast aluminium, plastic |
| Dimension housing (W×D×H) | 213×333×338 mm |
| Material weighing plate | stainless steel |
| Net weight approx. | 7 kg |
| Construction type of the scale | Single-range balance |
