Kern Precision Balance | PNS 600-3
The new standard in the laboratory with robust tuning fork weighing system.
- Adjusting program CAL for quick setting of the balance accuracy using an external test weight at an additional price, see test weights.
- High-quality tuning fork weighing system for rapid display of the weight, very precise dispensing and a high level of mechanical robustness.
- Capacity display: A bargraph display lights up to show how much of the weighing range is still available.
- Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value.
- Compact size, practical for small spaces.
- Large, shock proof weighing plate made of stainless steel.
- Large glass draught shield with 3 sliding doors for easy access to the items being weighed standard, weighing space W×D×H 172×171×160 mm.
- Protective working cover included with delivery.
Kern Precision Balance | PNS 600-3 Technical Data
| Weighing capacity [Max] | 620 g |
| Readability [d] | 0,001 g |
| Units | g, gn, dwt, tl (Tw), tl (HK), ozt, tl (Singap, Malays), mo, lb, oz, tol |
| Linearity | ± 0,004 g |
| Reproducibility | 0,001 g |
| Stabilization time | 3 s |
| USP Minimum weight of sample (k = 2, U = 0.1%) | 2 g |
| Interfaces | RS-232 standard |
| Adjustment options | Adjusting with external weight |
| Recommended adjusting weight | 600 g (E2) |
| Ambient temperature | 5 °C – 40 °C |
| Dimensions weighing surface (Ø) | 140 mm |
| Material draught shield | glass |
| Material housing | plastic |
| Dimension housing (W×D×H) | 196×293×266 mm |
| Material weighing plate | stainless steel |
| Net weight approx. | 2,2 kg |
| Construction type of the scale | Single-range balance |
Kern Precision Balance | PNS 600-3 Images
