Stock Code
0590 7603
TESTO Digital Multimeter | 760-3
Delivery Scope
The testo 760-3 is the most high-performance model in Testo's digital multimeter family. In addition to automatic detection of measurement parameters, it is characterized by a voltage measuring range of up to 1,000 V along with large measuring ranges for frequency and capacitance. The digital multimeter is therefore also suitable for industrial applications.
Your advantages
- Easy, reliable work thanks to automatic measurement parameter detection
- Comfortable, one-handed operation without any dial
- Voltage range up to 1,000 V
- Additional functions, such as true root mean square measurement - TRMS, low-pass filter and temperature adapter
TESTO Digital Multimeter | 760-3 Description
The testo 760-3 digital multimeter is the multitasker for all important professionals in the electricity sector. It enables you to carry out both simple and demanding electrical measuring tasks more reliably than ever before. The testo 760-3 automatically detects the appropriate measurement parameter via the socket assignment and so prevents dangerous incorrect settings.
A voltage range of up to 1,000 V, a frequency range of up to 60 MHz and capacitance of up to 60,000 µF mean the testo 760-3 multimeter can also be used for industrial applications, such as troubleshooting in large electrical systems. And the integrated low-pass filter achieves more accurate measurement results on frequency converter controlled motors.
Temperatures can also be measured with this multimeter in addition to electrical parameters. You will need the clip-on type K thermocouple adapter and a temperature probe (both items can be ordered separately).
Delivery Scope
testo 760-3 TRMS multimeter, including batteries, 1 set of measuring cables (0590 0010) and instruction manual.
TESTO Digital Multimeter | 760-3 Technical Data
Temperature - TC Type K (NiCr-Ni)
DC voltage
AC voltage
DC current
AC current
Resistance
Capacitance
General technical data
Instrument Measurement Functions
TESTO Digital Multimeter | 760-3 Image
Temperature - TC Type K (NiCr-Ni)
| Measuring range |
-20 to +500 °C
|
|---|---|
| Accuracy |
±1 °C (0 to +100 °C)
|
| Resolution |
0.2 °C
|
DC voltage
| Measuring range |
0.1 mV to 1000 V
|
|---|---|
| Resolution |
max. 0.1 mV
|
| Accuracy |
± (0.8 % of mv + 3 Digits)
|
AC voltage
| Measuring range |
0.1 mV to 1000 V
|
|---|---|
| Resolution |
max. 0.1 mV
|
| Accuracy |
± (1.0 % of mv + 3 Digits)
|
DC current
| Measuring range |
0.1 μA to 10 A
|
|---|---|
| Resolution |
max. 0.1 μA
|
| Accuracy |
± (1.5 % of mv + 5 Digits)
|
AC current
| Measuring range |
0.1 μA to 10 A
|
|---|---|
| Resolution |
max. 0.1 μA
|
| Accuracy |
± (1.5 % of mv + 5 Digits)
|
Resistance
| Resolution |
max. 0.01 Ohm
|
|---|---|
| Measuring range |
0.01 Ohm to 60.00 MOhm
|
| Accuracy |
± (1.5 % of mv + 3 Digits)
|
Capacitance
| Resolution |
max. 0.001 nF
|
|---|---|
| Measuring range |
0.001 nF to 60 mF
|
| Accuracy |
max. ± (1.5 % of mv + 5 Digits)
|
General technical data
| Operating humidity |
0 to 80 %RH
|
|---|---|
| Weight |
340 g
|
| Dimensions |
167 x 85 x 45 mm
|
| Operating temperature |
-10 to +50 °C
|
| Connectable probes |
1 x temperature probe (adapter required for type K thermocouples)
|
| Product colour |
Black
|
| Protection class |
IP64
|
| Standards |
EN 61326-1; EN 61010-2-033; EN 61140
|
| Battery type |
3 AAA micro batteries
|
| Display size |
2 lines
|
| Display type |
LCD (Liquid Crystal Display)
|
| Interface |
4 measuring jacks
|
| Storage temperature |
-15 to +60 °C
|
| Overvoltage Category |
CAT IV 600V; CAT III 1000V
|
| Authorizations |
CE; CSA
|
| Internal_resistance |
11 MOhm (AC / DC)
|
Instrument Measurement Functions
| Diode test |
yes
|
|---|---|
| Continuity testing |
yes
|
| Current probe measurement with adapter |
yes
|
| Display ligthing |
yes
|
| Hold |
yes
|
| MinMax |
yes
|
| Temperature measurement with adapter |
yes
|
| True RMS |
yes
|
| Low-pass filter |
yes
|
| Duty cycle measurement |
yes
|
| Display (counts) |
6,000
|
| Autom. measurement parameter detection |
yes
|
| μA current measuring range |
yes
|
